Features
Double circuit type of limit switch
Highly rigid construction, consists of intensive plastic and aluminum
cast (Head and cover snugly fit in box)
Small volume, water-proof and oil-proof construction
Built-in basic switch with double spring mechanism, longer mechanical Life
Easy-to-wire circuit opening design
Characteristics
|
Contact resistance
|
15mΩ max. (initial value)
|
|
Insulation resistance
|
100mΩ min.
|
|
Shock resistance
|
In the free position 10G, In the operation position 30G
|
|
Vibration resistance
|
Standard type Max 55Hz
|
|
Mechanical life
|
10,000,000 operations above
|
|
Electrical life
|
500,000 operations above
|
|
Ambient temperature
|
-20℃ to +60℃
|
|
Humidity
|
＜95%
|
|
Protection
|
IP64
|
